am currently having a Defender 110 rebuilt. Because I have three kids, I really wanted a 4-door Defender 110 instead of the 2-door Defender 90. Rather than track down a 1993 "1 of 500" D-110, I opted to take a low mileage 1997 Limited Addition D-90 and migrate it to a 110 frame. This means some modifications have to be made, including new rear tub, rear doors, rear windows, roof, drive shaft, wiring harness, brake lines etc.

This offers me the advantage of owning a much newer (and nicer) legal NAS 110--and it doesn't have to be Alpine White. For my 110, I've opted to keep the Limited Edition Willow Green. In addition, I will be adding some other goodies along the way, including an upgrade to a 4.6 liter V-8 for a little more power.

Not only will this be my driver, but it also needs to be my "family car", with three rows of seats to accommodate my growing family. So rather than going with the standard 4 jump seats in the back, It will have two, forward-facing third row folding seats from Exmoor installed.

Standard Vehicle Features

  • Limited edition number plaque

  • Air conditioning

  • Front bull bar

  • Rear bumper with integral step and Class III towing receiver

  • 16" Freestyle 5-spoke alloy wheels

  • Lockable cubby box

  • Auto-dimming rearview mirror

  • Side running boards

  • Heated front windshield

  • Heated rear window

  • Alpine windows

  • Detachable roof rack with rear access ladder

  • Seating Capacity: Nine (2 + 3 + 4] )

  • Interior: Slate grey vinyl

  • Color: Willow Green

Mechanics

  • Engine: 4.0 L V8 Engine

  • Gearbox: Automatic

  • Axle: Salisbury rear axle

  • Transfer box: Permanent four-wheel drive, two-speed with manual locking center differential

  • Brakes: Front: Vented disc, 4 piston calipers

  • Brakes: Rear: Disc, 2 piston calipers

  • Suspension: Solid axle front and rear, coil sprung, Front and Rear sway bar standard

  • Steering: Power assisted

  • Aluminum body bolted directly to chassis frame

Off Road Stats

  • Approach Angle: 51 degrees

  • Departure Angle: 35 degrees

Fuel Tank

  • 20.4 US Gallons

Weights

  • Estimated Curb Weight: 4,848lbs

  • Gross Vehicle Weight Rating (GVWR): 6,504lbs

Dimensions

  • Overall length: 181.1in/4599mm

  • Overall height (without rack): 81.3in/2065mm

  • Overall height (with rack): 90.0in/2286mm

  • Overall Width: 70.5in/1790mm

  • Wheelbase: 110.0 in/2794mm

  • Track front and rear: 58.5 in/1486mm

  • Ground clearance under differentail: 8.5 in/215mm

New & Modified

  • New 110" powder coated frame

  • 4.6 Liter V-8 engine

  • 4:11 gears

  • ARB air lockers

  • Old Man Emu coil sprung suspension

  • Southdown steering guard

  • BF Goodrich All-Terrain tires – 265/75R16

  • Warn XD9000 winch

  • New aluminum body panels

  • Willow green exterior paint

  • Sunroof

  • Full interior roll cage

  • External basket rack and rear access ladder

  • Shrockworks frame-mounted rear swinging tire carrier

  • CD changer with 6 speaker sound system

  • DVD entertainment system

  • GPS/Navigation System

  • Two forward-facing third row bucket seats (no jump seats) creating a 2 + 3 + 2 seating pattern

  • Inertia style seat belts on all 7 seats
